Digging deep into the AD DS workstation logon process – Part 1

Hi everyone. The holidays are over, spring is quickly approaching, and it’s been far too long since I’ve had a chance to do a deep dive. This year I have some work on the agenda for Microsoft Active Directory Domain Services (AD DS). That work will require a very strong understanding of the network flows, ports, and protocols that provide the service. While there are many different resources on the web, I haven’t found one that gets to the level I’d like to see. This made for the perfect opportunity for a series of blog posts.

Many of us have faced the challenge where there is a requirement to separate the domain controllers providing the AD DS service and the domain members with a firewall. Microsoft does a wonderful job defining the ports and protocols required for this scenario in this link (https://technet.microsoft.com/en-us/library/dd772723(v=ws.10).aspx). The integration is pretty straightforward with the only decision typically being whether to define static RPC ports or leveraging a firewall which is capable of handling dynamic RPC ports.

One of the things I’ve always wondered is when are each of these ports and protocols used? What better place to start than a common source for troubleshooting? For this series of blogs I will do a deep dive into the flows a domain-joined machine uses and what happens within those connections. Yeah I know, AD DS isn’t that glamorous in the year 2017, but all the moving parts, protocols, standards, and functions that power something as seemingly simple as a logon are fascinating and worth a deeper look.

To provide for this scenario I built a small lab in Azure with three Windows Server 2016 Standard VMs. Each VM is configured as seen below:

Name: DCSERVER
Roles: Active Directory Domain Services, DNS
IP: 10.0.10.101

Name: DC2
Roles: Active Directory Domain Services, DNS
IP: 10.0.10.102

Name: MEMBER
Roles: None
IP: 10.0.10.100

The AD DS forest uses the CONTOSO.LOCAL DNS namespace and has one custom site defined named FAKESITE. DCSERVER is servicing the Default-First-Site-Name and DC2 is servicing FAKESITE. FAKESITE has been assigned a subnet range that includes MEMBER. For tools I used Procmon to capture the registry entries that a domain-joined member’s Active Directory site is cached to. Additionally I used netsh to perform a network capture at boot up

Beyond the network flows, I was interested in observing the DCLocator (DSGetDcName) API behavior. I cleared the three registry entries listed below to ensure MEMBER would perform a DCLocator query at boot up. Additionally I used netsh to get a network capture at boot up (https://blogs.msdn.microsoft.com/canberrapfe/2012/03/30/capture-a-network-trace-without-installing-anything-capture-a-network-trace-of-a-reboot/) and Microsoft Network Monitor to analyze the capture.

– HKLMSystemCurrentControlSetServicesTcpipParametersDomain
– HKLMSystemCurrentControlSetServicesNetlogonParametersSiteName
– HKLMSystemCurrentControlSetServicesNetlogonParameterDynamicSiteName

With the background information taken care of, let’s jump into workstation authentication process.

  1. Source: Domain-joined machine
    Destination: Primary DNS Server
    Connection: UDP
    Port: 53
    Protocol: DNS
    Purpose: DsGetDcName API on domain-joined machine uses the information collected from the registries entries listed at the bottom of this step to issue a DNS query for an SRV record to the machine’s primary DNS server for a server offering an LDAP service _ldap._tcp.dc_msdsc.contoso.local. The primary DNS server returns the results of the SRV query.

    • HKLMSystemCurrentControlSetServicesTcpipParametersHostname
    • HKLMSystemCurrentControlSetServicesTcpipParametersDomain
    • HKLMSystemCurrentControlSetServicesTcpipParametersNameServer
    • HKLMSystemCurrentControlSetServicesTcpipParametersDhcpNameServer
    • HKLMSystemCurrentControlSetServiesNetlogonParametersSiteName
    • HKLMSystemCurrentControlSetServiesNetlogonParametersDynamicSiteName
  2. Source: Domain-joined machine
    Destination: Primary DNS Server
    Connection: UDP
    Port: 53
    Protocol: DNS
    Purpose: DSGetDcName API on domain-joined machine issues a DNS query for the A record of a domain controller from the results of the SRV query. The primary DNS server returns the results of the A record query.

  3. Source: Domain-joined machine
    Destination: Domain Controller
    Connection: UDP
    Port: 389
    Protocol: LDAP
    Purpose: DsGetDcName API on domain-joined machine issues a specially crafted LDAP query (referred to by Microsoft as an LDAP Ping) to the domain controller querying the RootDSE for the NetLogon attribute. The detail query is as follows:

    • Filter: (&(DnsDomain=)(Host=HOSTNAME)(DomainSID=)(DomainGUID=)(NtVer=)(DnsHostName=))
    • Attributes: NetLogon

    The domain controller passes the query to the NetLogon service running on the domain controller which evaluates the query to determine which site the server belongs in. The domain controller returns information about its state and provides the information detailed below (https://msdn.microsoft.com/en-us/library/cc223807.aspx):

    • Flags:
      • DSPDCFLAG – DC is PDC of the domain
      • DSGCFLAG – DC is a GC of the forest
      • DSLDAPFLAG – Server supports an LDAP server
      • DSDSFlag- DC supports a DS and is a domain controller
      • DSKDCFlag DC is running KDC service
      • DSTimeServFlag – DC is running time service
      • DSClosestFlag – DC is in the closest site to the client
      • DSWritableFLag – DC has a writable DS
      • DSGoodTimeServFlag (0) – DC is running time service
      • DSNDNCFlag – DomainName is a non-domain NC serviced by the LDAP server
      • DSSelectSecretDomain6Flag – the server is a not an RODC
      • DSFullSecretDomain6Flag – The server is a writable DC
      • DSWSFlag – The Active Directory Web Service is present on the server
      • DSDNSControllerFlag – DomainControllerName is not a DNS name
      • DSDNSDomainFlag – DomainName is not a DNS name
      • DSDNSForestFlag – DnsForestName is not a DNS name
    • DomainGuid:
    • DnsForestName: contoso.local
    • DnsDomainName: contoso.local
    • DnsHostName: DCSERVER.contoso.local
    • NetbiosDomainName: CONTOSO
    • NetbiosComputerName: DCSERVER
    • Username:
    • DcSiteName: Default-First-Site-Name
    • ClientSiteName: FAKESITE
    • NextClosestSIteName: Default-First-Site-Name

    The client caches this information to its DCLocator cache and will perform another LDAP Ping to another domain controller if it was determined the domain controller is not within the client’s site.

  4. Source: Domain-joined machine
    Destination: Same Site or Closest Site Domain Controller
    Connection: TCP
    Port: 445
    Protocol: SMB
    Purpose: The domain-joined workstation sends an SMB2 NEGOTIATE Request to the domain controller and receives back an SMB2 Negotiate Response. This process allows the machines to agree upon an authentication mechanism. This SMB session will be leveraged through the logon process to communicate with a domain controller’s SYSVOL to process group policy and run any startup scripts.
    Links:

  5. Source: Domain-joined machine
    Destination: Primary DNS Server
    Connection: UDP
    Port: 53
    Protocol: DNS
    Purpose: DsGetDcName API issues a DNS query for an SRV record to the machine’s primary DNS server for a domain controller offering the Kerberos service using the SRV record of _kerberos._tcp.dc._msdcs.contoso.local. The primary DNS server returns the results of the SRV query.

  6. Source: Domain-joined machine
    Destination: Domain Controller
    Connection: UDP
    Port: 389
    Protocol: LDAP
    Purpose: DsGetDcName API on domain-joined machine issues a specially crafted LDAP query (referred to by Microsoft as an LDAP Ping) to the domain controller querying the RootDSE for the NetLogon attribute. The detail query is as follows:

    • Filter: (&(DnsDomain=)(Host=HOSTNAME)(DomainGUID=)(NtVer=)(DnsHostName=))
    • Attributes: NetLogon

    The domain controller passes the query to the NetLogon service running on the domain controller which evaluates the query to determine which site the server belongs in. The domain controller returns information about its state and provides the information detailed below (https://msdn.microsoft.com/en-us/library/cc223807.aspx):

    • Flags
      • DSPDCFLAG – DC is PDC of the domain
      • DSGCFLAG – DC is a GC of the forest
      • DSLDAPFLAG – Server supports an LDAP server
      • DSDSFlag- DC supports a DS and is a domain controller
      • DSKDCFlag DC is running KDC service
      • DSTimeServFlag – DC is running time service
      • DSClosestFlag – DC is in the closest site to the client
      • DSWritableFLag – DC has a writable DS
      • DSGoodTimeServFlag (0) – DC is running time service
      • DSNDNCFlag – DomainName is a non-domain NC serviced by the LDAP server
      • DSSelectSecretDomain6Flag – the server is a notan RODC
      • DSFullSecretDomain6Flag – The server is a writable DC
      • DSWSFlag – The Active Directory Web Service is present on the server
      • DSDNSControllerFlag – DomainControllerName is not a DNS name
      • DSDNSDomainFlag – DomainName is not a DNS name
      • DSDNSForestFlag – DnsForestName is not a DNS name
    • DomainGuid:
    • DnsForestName: contoso.local
    • DnsDomainName: contoso.local
    • DnsHostName: DCSERVER.contoso.local
    • NetbiosDomainName: CONTOSO
    • NetbiosComputerName: DCSERVER
    • Username:
    • DcSiteName: Default-First-Site-Name
    • ClientSiteName: FAKESITE
    • NextClosestSIteName: Default-First-Site-Name

    The client caches this information to its DCLocator cache and will perform another LDAP Ping to another domain controller if it was determined the domain controller is not within the client’s site.

  7. Source: Domain-joined machine
    Destination: Same Site or Closest Site Domain Controller
    Connection: TCP
    Port: 88
    Protocol: Kerberos
    Purpose: The domain-joined machine attempts to verify its identity with the domain controller by sending a KRB-AS-REQ without pre-authentication data. The domain controller checks the object that represents the principal to determine if the account has the “Do not require Kerberos preauthentication.” If the option is not checked, the domain controller returns KRB_ERROR (25) indicating preauthentication data is required.

  8. Source: Domain-joined machine
    Destination: Same Site or Closest Site Domain Controller
    Connection: TCP
    Port: 88
    Protocol: Kerberos
    Purpose: The domain-joined machine re-attempts to verify its identity with the domain controller by sending a KRB-AS-REQ with pre-authentication data. The domain controller validates the principal’s identity and responds with a KRB-AS-REP which includes a Kerberos TGT for the principal to use to obtain additional Kerberos service tickets.

  9. Source: Domain-joined machine
    Destination: Same Site or Closest Site Domain Controller
    Connection: TCP
    Port: 88
    Protocol: Kerberos
    Purpose: The domain-joined machine requests a service ticket for CIFS service running on the domain controller by sending a KRB-TGS-REQ for the CIFS service principal. The domain controller validates the machine’s Kerberos TGT and returns a service ticket for the CIFS service. The domain-joined machine will use the service ticket to authenticate to the SMB service in order to access the SYSVOL share.

  10. Source: Domain-joined machine
    Destination: Same Site or Closest Site Domain Controller
    Connection: TCP
    Port: 88
    Protocol: Kerberos
    Purpose: The domain-joined machine requests a service ticket for CIFS service running on the domain controller by sending a KRB-TGS-REQ for the CIFS service principal name. The domain controller validates the machine’s Kerberos TGT and returns a service ticket for the CIFS service. The domain-joined machine will use the service ticket to authenticate to the SMB service in order to access the SYSVOL share.

  11. Source: Domain-joined machine
    Destination: Same Site or Closest Site Domain Controller
    Connection: TCP
    Port: 88
    Protocol: Kerberos
    Purpose: The domain-joined machine requests a Kerberos TGT by sending a KRB-TGS-REQ for the KRBTGT service principal name. I have to admit, I’m pretty clueless on this one. The only usage I can find online references cross realm.

As you can see, there’s a ton of interesting chatter that only gets more interesting once we begin breaking down the SMB conversation. The SMB portion involved a ton of reading on my end, because I haven’t often done any deep dive troubleshooting into the protocol. As always, I’ll include the links that helped me along the learning path as we cruise through those sections. See you on the next post!

Azure AD User Provisioning – Part 5

Hi everyone. I apologize for the delay in publishing the last post in this series. The past few months have been hectic. For this last post of the year I will be completing the series on provisioning in Azure AD.

As I’ve covered in earlier posts, there are a lot of options when provisioning to Azure AD including multiple GUIs and programmatic options. I’ve covered provisioning in the Azure Management Portal, Azure Portal, Office 365 Admin Center, and Azure Active Directory PowerShell v1 and v2. In this final post I will cover provisioning via the Graph API using a simple ASP .NET web application.

I was originally going to leverage the graph API directly via PowerShell using the .NET ADAL libraries and Invoke-WebRequest cmdlets. I’ve been playing around a lot with Visual Studio creating simple applications like the Azure B2B provisioning app. I decided to challenge myself by adding additional functionality to the ASP .NET web application I assembled in my previous post. I enjoyed the hell out of the process, learned a bunch more about .NET, C#, ASP .NET web apps, and applications built using the MVC architecture. Let’s get to it shall we?

Before we dive into the code and the methodologies I used to put together the application, let’s take a look at it in action. The application starts by requiring authentication to Azure AD.

1

After successful authentication, the main page for the website loads. You’ll notice from the interface that I used the sample ASP .NET MVC Web Application available in Visual Studio but added a new navigation link on the right hand side named Create User.

2

After clicking the Create User link, the user is redirected to a simple (i.e. ugly) web form where information about the new user is collected.

3

After the user hits submit, the new user is created in Azure AD and the information from the returned JWT is parsed and displayed in a table.

4

When we navigate to the Azure AD blade in the Azure Portal we see that Homer has been created and added to the system.

clearme

So you’re probably asking the question as to how complicated it was to put this application together? The answer may surprise you. It was incredibly simple. The most difficult part of the process was learning my away around C# and how MVC web apps are put together. For a skilled developer, this would have taken an hour versus the days it took me.

The first thing I did was do some reading into the Graph API, specifically around managing users. Microsoft has a number of great instructions located here and here. After getting familiar with the required inputs and the outputs, I built a new model in my application that would be used for the user form input.

6

Once I had my new model assembled, I then created two new views under a new folder named Create User. The view named Index is the view that takes the user input and the view named Results is the view that spits back some of the content from the JWT returned from Azure after the user is successfully created. Here is the code for the Index view.

7

And the code for the Results view.

8

After the new views were created, I then moved on to creating the guts of the new functionality with a new controller named CreateUserController. I was able to reuse some of the code from the UserProfileController to obtain the necessary OAuth access token to delegate the rights to the application to create the new user.

9

The remaining code in my controller came from a crash course in programming and MVC web apps. The first section of code calls the task to obtain the access token.

10

The next section of code creates a new instance of the user class and populates the properties with information collected from the form.


The final section of code attempts to create the new user and displays the results page with information about the user such as objectID and userPrincipalName. If the application is unable to create the user, the exception is caught, and an error page is displayed.

12

But wait… what is missing? I’ll give you a hint, it’s not code.

The answer is the appropriate delegated permissions. Even if the user is a global admin, the application can’t perform the actions of a global admin unless we allow it to. To make this happen, we’ll log into the Azure Portal, access the Azure AD blade, and grant the application the delegated permission to Access the directory as the signed-in user.

13

Simple right? The Azure Active Directory Graph Client libraries make the whole process incredibly easy doing a whole lot with very little code. Imagine integrating this functionality into an existing service catalog. Let’s say you have a business user who needs access to Dynamics CRM Online. The user could navigate to the service catalog and request access. After their manager approvers, the application powering the service catalog could provision the new user, assign the license for Dynamics CRM Online, and drop the user into the appropriate groups. All of this could happen without having to involve IT. This is the value of a simple API with a wonderful set of libraries.

Well folks that wraps up my last post the year. I’ll return next year with a series of deep dives exploring Microsoft’s newly announced Azure AD Pass-through authentication and SSO features. Have a happy holiday!

Azure AD ASP .NET Web Application

Hi all. Before I complete my series on Azure AD Provisioning with a look at how provisioning works with the Graph API, I want to take a detour and cover some Microsoft Visual Studio. Over the past month I’ve been spending some time building very basic applications.

As I’ve covered previously in my blog, integration is going to the primary responsibility of IT Professionals as more infrastructure shifts to the cloud. Our success at integration will largely depend on how well we understand the technologies, our ability to communicate what business problems these technologies can solve, and our understanding of how to help developers build applications to consume these technologies. In my own career, I’ve spent a significant time on all of the above except the last piece. That is where I’m focusing now.

Recently I built a small.NET forms application that integrated with the new Azure AD B2B API. Over the past few days I’ve been spending time diving with to ASP .NET Web Applications built with an MVC architecture. I decided to build an small MVC application that performed queries against the Graph API, and wow was it easy. There was little to no code that I had to provide myself and “it just worked”. You can follow these instructions if you’d like to play with it as well. If you’ve read this blog, you know I don’t do well with things that just work. I need to know how it works.

If you follow the instructions in the above link you will have a ASP .NET Web Application that is integrated with your Azure AD tenant, uses Azure AD for authentication via the Open ID Connect protocol, and is capable of reading directory data from the Graph API uses OAuth 2.0. So how is all this accomplished? What actually happened? What protocol is being used for authentication, how does the application query for directory data? Those are the questions I’ll focus on answering in this blog post.

Let’s first answer the question as to what Visual Studio did behind the scenes to integrate the application with Azure AD. In the explanation below I’ll be using the technology terms (OAuth 2.0 and Open ID Connect) in parentheses to translate the Microsoft lingo. During the initialization process Visual Studio communicated with Azure AD (Authorization Server) and registered (registration) the application (confidential client) with Azure AD as a Web App and gave it the delegated permissions (scopes) of “Sign in and read user profile” and “Read directory data”.

In addition to the registration of the application in Azure AD, a number of libraries and code have been added to the project that make the authentication and queries to the Graph API “out of the box”. All of the variables specific to the application such as Client ID, Azure AD Instance GUID, application secret key are stored in the web.config. The Startup.cs has the simple code that adds Open ID Connect authentication. Microsoft does a great job explaining the Open ID Connect code here. In addition to the code to request the Open ID Connect authentication, there is code to exchange the authorization code for an access token and refresh token for the Graph API as seen below with my comments.

AuthorizationCodeReceived = (context) =>
{
var code = context.Code;
// MF -> Create a client credential object with the Client ID and Application key
ClientCredential credential = new ClientCredential(clientId, appKey);
// MF -> Extract the access token from cache and generate an authentication context from it
string signedInUserID = context.AuthenticationTicket.Identity.FindFirst(ClaimTypes.NameIdentifier).Value;
AuthenticationContext authContext = new AuthenticationContext(Authority, new ADALTokenCache(signedInUserID));
// MF -> Acquire a token by submitting the authorization code, providing the URI that is registered for the application, the application secret key, and the resource (in this scenario the Graph API)
AuthenticationResult result = authContext.AcquireTokenByAuthorizationCode(
code, new Uri(HttpContext.Current.Request.Url.GetLeftPart(UriPartial.Path)), credential, graphResourceId);
return Task.FromResult(0);
}

Now that the user has authenticated and the application has a Graph API access token, I’ll hop over to the UserProfileController.cs. The code we’re concerned about in here is below with my comments.


{
Uri servicePointUri = new Uri(graphResourceID);
Uri serviceRoot = new Uri(servicePointUri, tenantID);
ActiveDirectoryClient activeDirectoryClient = new ActiveDirectoryClient(serviceRoot, async () => await GetTokenForApplication());
// MF -> Use the access token previous obtained to query the Graph API
var result = await activeDirectoryClient.Users.Where(u => u.ObjectId.Equals(userObjectID)).ExecuteAsync();
IUser user = result.CurrentPage.ToList().First();
return View(user);
}

Next I’ll hop over to the UserProfile view to look at the Index.cshtml. In this file a simple table is constructed that returns information about the user from the Graph API. I’ve removed some of the pesky HTML and replaced it with the actions.


@using Microsoft.Azure.ActiveDirectory.GraphClient
@model User
@{
ViewBag.Title = "User Profile";
}
"CREATE TABLE"
"TABLE ROW"
Display Name
@Model.DisplayName
"TABLE ROW"
First Name
@Model.GivenName
"TABLE ROW"
Last Name
@Model.Surname
"TABLE ROW"
Email Address
@Model.Mail

Simple right? I can expand that table to include any attribute exposed via the Graph API. As you can see in the above, I’ve added email address to the display. Now that we’ve reviewed the code, let’s cover the steps the application takes and what happens in each step:

  1. App accesses https://login.microsoftonline.com//.well-known/openid-configuration
    • Get OpenID configuration for Azure AD
  2. App accesses https://login.microsoftonine.com/common/discovery/keys
    • Retrieve public-keys used to verify signature of open id connect tokens
  3. User’s browser directed to https://login.microsoftonline.com//oauth2/authorize
    • Request an open id connect id token and authorization code for user’s profile information
  4. User’s browser directed to https://login.microsoftonline.com//login
    • User provides credentials to AAD and receives back
      1. id token
      2. access code for graph API with Directory.Read, User.Read scope
  5. User’s browser directed back to application
    • Return id token and access code to application
      1. id token authenticates user to application
      2. Access code for graph API with Directory.Read, User.Read scope temporarily stored
  6. Application accesses https://login.microsftonine.com//oauth2/token
    • Exchanges access code for bearer token
  7. Application sends OData query to Graph API and attaches bearer token.

That’s it folks! In my next post I will complete the Azure AD Provisioning series with a simple ASP .NET Web app that provisions new users into Azure AD.
