AI Foundry – Identity, Authentication and Authorization

Posted on January 27, 2025 by mattfeltonma

This is a part of my series on AI Foundry:

Updates:

3/17/2025 – Updated diagrams to include new identities and RBAC roles that are recommended as a minimum

Yes, I’m going to re-use the outline from my Azure OpenAI series. You wanna fight about it? This means we’re going to now talk about one of the most important (as per usual) and complicated (oh so complicated) topic in AI Foundry: identity, authentication, and authorization. If you haven’t read my prior two posts, you should take a few minutes and read through them. They’ll give you the baseline you’ll need to get the most out of this post. So put on your coffee, break out the metal clips to keep your eyes open Clockwork Orange-style, and prepare for a dip into the many ways identity, authN, and authZ are handled within the service.

As I covered in my first post Foundry is made up of a ton of different services. Each of these services plays a part in features within Foundry, some may support multiple forms of authentication, and most will be accessed by the many types of identities used within the product. Understanding how each identity is used will be critical in getting authorization right. Missing Azure RBAC role assignments is the number one most common misconfiguration (right above networking, which is also complicated as we’ll see in a future post).

Let’s start first with identity. There will generally be four types of identities used in AI Foundry. These identities will be a combination of human identities and non-human identities. Your humans will be your AI Engineers, developers, and central IT and will use their Entra ID user identities. Your non-humans will include the AI Foundry hub, project, and compute you provision for different purposes. In general, identities are used in the following way (this is not inclusive of all things, just the ones I’ve noticed):

Humans
- Entra ID Users
  - Actions within Azure Portal
  - Actions within AI Foundry Studio
    - Running a prompt flow from the GUI
    - Using the Chat Playground to send prompts to an LLM
    - Running the Chat-With-Your-Data workflow within the Chat Playground
    - Creating a new project within a hub
  - Actions using Azure CLI such as sending an inference to a managed online endpoint that supports Entra ID authentication
Non-Humans
- AI Foundry Hub Managed Identity
  - Accessing the Azure Key Vault associated with the Foundry instance to create secrets or pull secrets when AI Foundry connections are created using credentials versus Entra ID
  - Modify properties of the default Azure Storage Account such as setting CORS policies
  - Creating managed private endpoints for hub resources if a managed virtual network is used
- AI Foundry Project Managed Identity
  - Accessing the Azure Key Vault associated with the Foundry instance to create secrets or pull secrets when AI Foundry connections are created using credentials versus Entra ID
  - Creating blob containers for project where project artifacts such as logs and metrics are stored
  - Creating file share for project where project artifacts such as user-created Prompt Flow files are stored
- Compute
  - Pulling container image from Azure Container Registry when deploying prompt flows that require custom environments
  - Accessing default storage account project blob container to pull data needed to boot
  - Much much more in this category. Really depends on what you’re doing

Alright, so you understand the identities that will be used and you have a general idea of how they’ll be used to perform different tasks within the Foundry ecosystem. Let’s now talk authentication.

Authentication in Foundry isn’t too complicated (in comparison to identity and authorization). Authenticating to the Azure Portal and the Foundry Studio is always going to be Entra ID-based authentication. Authentication to other Azure resources from the Foundry is where it can get interesting. As I covered in my prior post, Foundry will typically support two methods of authentication: Entra ID and API key based (or credentials as you’ll see it often referred to as in Foundry). If at all possible, you’ll want to lean into Entra ID-based authentication whenever you access a resource from Foundry. As we’ll see in the next section around authorization, this will have benefits. Besides authorization, you’ll also get auditability because the logs will show the actual security principal that accessed the resource.

If you opt to use credential-based authentication for your connections to Azure resources, you’ll lose out in a few different areas. When credential-based authentication is used, users will access connected resources within Foundry using the keys stored in the Foundry connection object. This means the user assumes whatever permissions the key has (which is typically all data-plane permissions but could be more restrictive in instances like a SAS token). Besides the authorization challenges, you’ll also lose out on traceability. AI Foundry (and the underlining Azure Machine Learning) has some authorization (via Azure RBAC roles) that is used to control access to connections, but very little in the way auditing who exercised what connection when. For these reasons, you should use Entra ID where possible.

Ready for authorization? Nah, not yet. Before we get into authorization, it’s important to understand that these identities can be used in generally two ways: direct or indirect (on-behalf-of). For example, let’s say you run a Prompt Flow from AI Foundry interface, while the code runs on a serverless compute provisioned in a Microsoft managed network (more on that in a future post), the identity context it uses to access downstream resources is actually yours. Now if you deploy that same prompt to a managed online-endpoint, the code will run on that endpoint and use the managed identity assigned to the compute instance. Not so simple is it?

So how do you know which identity will be used? Observe my general guidance from up above. If you’re running things from the GUI, likely your identity, if you’re deploying stuff to compute likely the identity associated with the compute. The are exceptions to the rule. For example, when you attempt to upload data for fine-tuning or using the on-your-own-data feature in the Chat Playground, and your default storage account is behind a private endpoint your identity will be used to access the data, but the managed identity associated with the project is used to access the private endpoint resource. Why it needs access to the Private Endpoint? I got no idea, it just does. If you don’t, good luck to you poor soul because you’re going to have hell of time troubleshooting it.

Another interesting deviation is when using the Chat Playground Chat With Your Data feature. If you opt to add your data and build the index directly within AI Foundry, there will be a mixed usage of the user identity, AI Search managed identity (which communicates with the embedding models deployed in the AI Services or Azure OpenAI instance to create the vector representations of the chunks in the index), and AI Services or Azure OpenAI managed identity (creates index and data sources in AI Search). It can get very complex.

The image below represents most of the flows you’ll come across.

**The many AI Foundry authentication flows and identity patterns**

Okay, now authorization? Yes, authorization. I’m not one for bullshitting, so I’ll just tell you up front authorization in Foundry can be hard. It gets even harder when you lock down networking because often the error messages you will receive are the same for blocked traffic and failed authorization. The complexities of authorization is exactly why I spent so much time explaining identity and authentication to you. I wish I could tell you every permission in every scenario, but it would take many, many, posts to do that. Instead, I’d advise you to do (sometimes I fail to do this) which is RTFM (go ahead and Google that). This particular product group has made strong efforts to document required permissions, so your first stop should always be the Foundry public documentation. In some instances, you will also need to access the Azure Machine Learning documentation (again, this is built on top of AML) because there are sometimes assumptions that you’ll do just that because you should know this is a feature its inheriting from AML (yeah, not fair but it’s reality).

In general, at an absolute minimum, the permissions assigned to the identities below will get you started as of the date of this post (updated 3/17/2025).

As I covered in my prior posts, the AI Foundry Hub can use either a system-assigned or user-assigned managed identity. You won’t hear me say this often, but just use the system-assigned managed identity if you can for the hub. The required permissions will be automatically assigned and it will be one less thing for you to worry about. Using the permissions listed above should work for a user-assigned managed identity as well (this is on my backburner to re-validate).

A project will always use a system assigned managed identity. The only permission listed above that you’ll need to manually grant is Reader over the Private Endpoint for the default storage account. This is only required if you’re using private endpoint for your default storage account. There may be additional permissions required by the project depending on the activities you are performing and data you are accessing.

On the user side the permissions above will put you in a good place for your typical developer or AI engineer to use most of the features within Foundry. If you’re interacting with other resources (such as an AI Search Index when using the on-your-own-data feature) you’ll need to ensure the user is granted appropriate permissions to those resources as well (typically Search Service Contributor – management plane to list indexes and create indexes and Search Index Data Contributor – data plane create and view records within an index. If your user is fine-tuning a model that is deployed within the Azure OpenAI or AI Service instance, they may additionally need the Azure OpenAI Service Contributor role (to upload the file via Foundry for fine-tuning). Yeah, lots of scenarios and lots of varying permissions for the user, but that covers the most common ones I’ve run into.

Lastly, we have the compute identities. There is no standard here. If you’ve deployed a prompt flow to a managed identity, the compute will need the permissions to connect to the resources behind the connections (again assuming Entra-ID is configured for the connection, if using credential Azure Machine Learning Workspace Secrets Reader on the project is likely sufficient). Using a prompt flow that requires a custom environment may require an image be pushed to the Azure Container Registry which the compute will pull so it will need the Acr Pull RBAC role assignment on the registry.

Complicated right? What happens when stuff doesn’t work? Well, in that scenario you need to look at the logs (both Azure Activity Log and diagnostic logging for the relevant service such as blob, Search, OpenAI and the like). That will tell you what the user is failing to do (again, only if you’re using Entra ID for your connections) and help you figure out what needs to be added from a permissions perspective. If you’re using credentials for your connections, the most common issue with them is with the default storage account where the storage account has had the storage access keys disabled.

Here are the key things I want you to take away from this:

Know the identity being used. If you don’t know which identity is being used, you’ll never get authorization right. Use the of the downstream service logs if you’re unsure. Remember, management plane stuff in Azure Activity Log and data plane stuff in diagnostic logs.
Use Entra ID authentication where possible. Yeah it will make your Azure RBAC a bit more challenging, but you can scope the access AND understand who the hell is doing what.
RTFM where possible. Most of this is buried in the public documentation (sometimes you need to put on your Indiana Jones hat). Remember that if you don’t find it in Foundry documentation, look to Azure Machine Learning.
Use the above information as general guide to get the basic environment setup. You’ll build from that basic foundation.

Alrighty folks, your eyes are likely heavy. I hope this helps a few souls out there who are struggling with getting this product up and running. If you know me, you know I’m no fan boy, but this particular product is pretty damn awesome to get us non-devs immediately getting value from generative AI. It may take some effort to get this product running, but it’s worth it!

Thanks and see you next post!

Authentication in Azure OpenAI Service

Posted on April 2, 2023 by mattfeltonma

This is part of my series on the Azure OpenAI Service:

Updates:

1/18/2024 to reference considerable library changes with new API version. See below for details
4/3/2023 with simpler way to authenticate with Azure AD via Python SDK

Hello again!

1/18/2024 Update – Hi folks! There were some considerable changes to the OpenAI Python SDK which offers an even simpler integration with the Azure OpenAI Service. While the code in this post is a bit dated, I feel the thought process is still important so I’m going to preserve it as is! If you’re looking for examples of how to authenticate with the Azure OpenAI Service using the Python SDK with different types of authentication (service principal vs managed identity) or using the REST API, I’ve placed a few examples in this GitHub repository. Hope it helps!

Days and nights have been busy diving deeper into the AI landscape. I’ve been reading a great book by Tom Taulli called Artificial Intelligence Basics: A Non-Technical Introduction. It’s been a huge help in getting down the vocabulary and understanding the background to the technology from the 1950s on. In combination with the book, I’ve been messing around a lot with Azure’s OpenAI Service and looking closely at the infrastructure and security aspects of the service.

In my last post I covered the controls available to customers to secure their specific instance of the service. I noted that authentication to the service could be accomplished using Azure Active Directory (AAD) authentication. In this post I’m going to take a deeper look at that. Be ready to put your geek hat on because this post will be getting down and dirty into the code and HTTP transactions. Let’s get to it!

Before I get into the details of how supports AAD authentication, I want to go over the concepts of management plane and data plane. Think of management plane for administration of the resource and data plane for administration of the data hosted within the resource. Many services in Azure have separate management planes and data planes. One such service is Azure Storage which just so happens to have similarities with authentication to the OpenAI Service.

When a customer creates an Azure Storage Account they do this through interaction with the management plane which is reached through the ARM API hosted behind management.azure.come endpoint. They must authenticate against AAD to get an access token to access the API. Authorization via Azure RBAC then takes place to validate the user, managed identity, or service principal has permissions on the resource. Once the storage account is created, the customer could modify the encryption key from a platform managed key (PMK aka key managed by Microsoft) to a customer managed key (CMK), enable soft delete, or enable network controls such as the storage firewall. These are all operations against the resource.

Once the customer is ready to upload blob data to the storage account, they will do this through a data plane operation. This is done through the Blob Service API. This API is hosted behind the blob.core.windows.net endpoint and operations include creation of a blob or deletion of a blob. To interact with this API the customer has two means of authentication. The first method is the older method of the two and involves the use of static keys called storage account access keys. Every storage account gets two of these keys when a storage account is provisioned. Used directly, these keys grant full access to all operations and all data hosted within the storage account (SAS tokens can be used to limit the operations, time, and scope of access but that won’t be relevant when we talk the OpenAI service). Not ideal right? The second method is the recommended method and that involves AAD authentication. Here the security principal authenticates to AAD, receives an access token, and is then authorized for the operation via Azure RBAC. Remember, these are operations against the data hosted within the resource.

**Authentication in Management Plane vs Data Plane in Azure Storage**

Now why did I give you a 101 on Azure Storage authentication? Well, because the Azure OpenAI Service works in a very similar way.

Let’s first talk about the management plane of the Azure OpenAI Service. Like Azure Storage (and the rest of Azure’s services) it is administered through the ARM API behind the management.azure.com endpoint. Customers will use the management plane when they want to create an instance of the Azure OpenAI Service, switch it from a PMK to CMK, or setup diagnostic settings to redirect logs (I’ll cover logging in a future post). All of these operations will require authentication to AAD and authorization via Azure RBAC (I’ll cover authorization in a future post).

Simple right? Now let’s move to the complexity of the data plane.

Two API keys are created whenever a customer creates an Azure OpenAI Service instance. These API keys allow the customer full access to all data plane operations. These operations include managing a deployment of a model, managing training data that has been uploaded to the service instance and used to fine tune a model, managing fine tuned models, and listing available models. These operations are performed against the Azure OpenAI Service API which lives behind a unique label with an FQDN of openai.azure.com (such as myservice.openai.azure.com). Pretty much all the stuff you would be doing through the Azure OpenAI Studio. If you opt to use these keys you’ll need to remember control access to these keys via securing management plane authorization aka Azure RBAC.

In the above image I am given the option to regenerate the keys in the case of compromise or to comply with my organization’s key rotation process. Two keys are provided to allow for continued access to the service while other key is being rotated.

Here I have simple bit of code using the OpenAI Python SDK. In the code I provide a prompt to the model and ask it to complete it for me and use one of the API keys to authenticate to it.

import logging
import sys
import os
import openai

def main():
    # Setup logging
    try:
        logging.basicConfig(
            level=logging.ERROR,
            format='%asctime)s - %(name)s - %(levelname)s - %(message)s',
            handlers=[logging.StreamHandler(sys.stdout)]
        )
    except:
        logging.error('Failed to setup logging: ', exc_info=True)

    try:

        # Setup OpenAI Variables
        openai.api_type = "azure"
        openai.api_base = os.getenv('OPENAI_API_BASE')
        openai.api_version = "2022-12-01"
        openai.api_key = os.getenv('OPENAI_API_KEY')

        response = openai.Completion.create(
            engine=os.getenv('DEPLOYMENT_NAME'),
            prompt='Once upon a time'
        )

        print(response.choices[0].text)

    except:
        logging.error('Failed to respond to prompt: ', exc_info=True)


if __name__ == "__main__":
    main()

The model gets creative and provides me with the response below.

If you look closely you’ll notice an warning about the security of my session. The reason I’m getting that error is shut off certificate verification in the OpenAI library in order to intercept the calls with Fiddler. Now let me tell you, shutting off certificate verification was a pain in the ass because the developers of the SDK are trying to protect users from the bad guys. Long story short, the Azure Python SDK doesn’t provide an option to turn off certificate checking like say the Azure Python SDK (which you can pass a kwarg of verify=False to turn it off in the request library used underneath). While the developers do provide a property called verify_ssl_certs, it doesn’t actually do anything. Since most Python SDKs use the requests library underneath the hood, I went through the library on my machine and found the api_requestor.py file. Within this file I modified the _make_session function which is creating a requests Sessions object. Here I commented out the developers code and added the verify=False property to the Session object being created.

**Turning off certificate verification in OpenAI Python SDK**

Now don’t go and do this in any environment that matters. If you’re getting a certificate verification failure in your environment you should be notifying your information security team. Certificate verification is an absolute must to ensure the identity of the upstream server and to mitigate the risk of man-in-the-middle attacks.

Once I was able to place Fiddler in the middle of the HTTPS session I was able to capture the conversation. In the screenshot below, you can see the SDK passing the api-key header. Take note of that header name because it will become relevant when we talk AAD authentication. If you’re using OpenAI’s service already, then this should look very familiar to you. Microsoft was nice enough to support the existing SDKs when using one of the API keys.

At this point you’re probably thinking, “That’s all well and good Matt, but I want to use AAD authentication for all the security benefits AAD provides over a static key.” Yeah yeah, I’m getting there. You can’t blame me for nerding out a bit with Fiddler now can you?

Alright, so let’s now talk AAD authentication to the data plane of the Azure OpenAI Service. Possible? Yes, but with some caveats. The public documentation illustrates an example of how to do this using curl. However, curl is great for a demonstration of a concept, but much more likely you’ll be using an SDK for your preferred programming language. Since Python is really the only programming language I know (PowerShell doesn’t count and I don’t want to show my age by acknowledging I know some Perl) let me demonstrate this process using our favorite AAD SDK, MSAL.

For this example I’m going to use a service principal, but if your code is running in Azure you should be using a managed identity. When creating the service principal I granted it the Cognitive Services User RBAC role on the resource group containing the Azure OpenAI Service instance as suggested in the documentation. This is required to authorize the service principal access to data plane operations. There are a few other RBAC roles for the service, but as I said earlier, I’ll cover authorization in a future post. Once the service principal was created and assigned the appropriate RBAC role, I modified my code to include a function which calls MSAL to retrieve an access token with the access scope of Cognitive Services, which the Azure OpenAI Service falls under. I then pass that token as the API key in my call to the Azure OpenAI Service API.

import logging
import sys
import os
import openai
from msal import ConfidentialClientApplication

def get_sp_access_token(client_id, client_credential, tenant_name, scopes):
    logging.info('Attempting to obtain an access token...')
    result = None
    print(tenant_name)
    app = ConfidentialClientApplication(
        client_id=client_id,
        client_credential=client_credential,
        authority=f"https://login.microsoftonline.com/{tenant_name}",
    )
    result = app.acquire_token_for_client(scopes=scopes)

    if "access_token" in result:
        logging.info('Access token successfully acquired')
        return result['access_token']
    else:
        logging.error('Unable to obtain access token')
        logging.error(f"Error was: {result['error']}")
        logging.error(f"Error description was: {result['error_description']}")
        logging.error(f"Error correlation_id was: {result['correlation_id']}")
        raise Exception('Failed to obtain access token')

def main():
    # Setup logging
    try:
        logging.basicConfig(
            level=logging.ERROR,
            format='%asctime)s - %(name)s - %(levelname)s - %(message)s',
            handlers=[logging.StreamHandler(sys.stdout)]
        )
    except:
        logging.error('Failed to setup logging: ', exc_info=True)

    try:
        # Obtain an access token
        token = get_sp_access_token(
            client_id = os.getenv('CLIENT_ID'),
            client_credential = os.getenv('CLIENT_SECRET'),
            tenant_name = os.getenv('TENANT_ID'),
            scopes = "https://cognitiveservices.azure.com/.default"
        )
    except:
        logging.error('Failed to obtain access token: ', exc_info=True)

    try:
        # Setup OpenAI Variables
        openai.api_type = "azure"
        openai.api_base = os.getenv('OPENAI_API_BASE')
        openai.api_version = "2022-12-01"
        openai.api_key = token

        response = openai.Completion.create(
            engine=os.getenv('DEPLOYMENT_NAME'),
            prompt='Once upon a time'
        )

        print(response.choices[0].text)

    except:
        logging.error('Failed to summarize file: ', exc_info=True)


if __name__ == "__main__":
    main()

Let’s try executing that and see what happens.

Uh-oh! What happened? If you recall from earlier the API key is passed in the api-key header. However, to use the access token provided by AAD we have to pass it in the authorization header as seen in the example in Microsoft public documentation.

curl ${endpoint%/}/openai/deployments/YOUR_DEPLOYMENT_NAME/completions?api-version=2022-12-01 \
-H "Content-Type: application/json" \
-H "Authorization: Bearer $accessToken" \
-d '{ "prompt": "Once upon a time" }'

Thankfully there is a solution to this one without requiring you to modify the OpenAI SDK. If you take a look in the api_requestor.py file again in the library you will see it provides the ability to override the headers passed in the request.

With this in mind, I made a few small modifications. I removed the api_key property and added an Authorization header to the request to the Azure OpenAI Service API which includes the access token received back from AAD.

import logging
import sys
import os
import openai
from msal import ConfidentialClientApplication

def get_sp_access_token(client_id, client_credential, tenant_name, scopes):
    logging.info('Attempting to obtain an access token...')
    result = None
    print(tenant_name)
    app = ConfidentialClientApplication(
        client_id=client_id,
        client_credential=client_credential,
        authority=f"https://login.microsoftonline.com/{tenant_name}",
    )
    result = app.acquire_token_for_client(scopes=scopes)

    if "access_token" in result:
        logging.info('Access token successfully acquired')
        return result['access_token']
    else:
        logging.error('Unable to obtain access token')
        logging.error(f"Error was: {result['error']}")
        logging.error(f"Error description was: {result['error_description']}")
        logging.error(f"Error correlation_id was: {result['correlation_id']}")
        raise Exception('Failed to obtain access token')

def main():
    # Setup logging
    try:
        logging.basicConfig(
            level=logging.ERROR,
            format='%asctime)s - %(name)s - %(levelname)s - %(message)s',
            handlers=[logging.StreamHandler(sys.stdout)]
        )
    except:
        logging.error('Failed to setup logging: ', exc_info=True)

    try:
        # Obtain an access token
        token = get_sp_access_token(
            client_id = os.getenv('CLIENT_ID'),
            client_credential = os.getenv('CLIENT_SECRET'),
            tenant_name = os.getenv('TENANT_ID'),
            scopes = "https://cognitiveservices.azure.com/.default"
        )
    except:
        logging.error('Failed to obtain access token: ', exc_info=True)

    try:
        # Setup OpenAI Variables
        openai.api_type = "azure"
        openai.api_base = os.getenv('OPENAI_API_BASE')
        openai.api_version = "2022-12-01"

        response = openai.Completion.create(
            engine=os.getenv('DEPLOYMENT_NAME'),
            prompt='Once upon a time',
            headers={
                'Authorization': f'Bearer {token}'
            }


        )

        print(response.choices[0].text)

    except:
        logging.error('Failed to summarize file: ', exc_info=True)


if __name__ == "__main__":
    main()

Running the code results in success!

4/3/2023 Update – Poking around today looking at another aspect of the service, I came across this documentation on an even simpler way to authenticate with Azure AD without having to use an override. In the code below, I specify an openai.api_type of azure_ad which allows me to pass the token direct via the openai_api_key property versus having to pass a custom header. Definitely a bit easier!

import logging
import sys
import os
import openai
from msal import ConfidentialClientApplication

def get_sp_access_token(client_id, client_credential, tenant_name, scopes):
    logging.info('Attempting to obtain an access token...')
    result = None
    print(tenant_name)
    app = ConfidentialClientApplication(
        client_id=client_id,
        client_credential=client_credential,
        authority=f"https://login.microsoftonline.com/{tenant_name}",
    )
    result = app.acquire_token_for_client(scopes=scopes)

    if "access_token" in result:
        logging.info('Access token successfully acquired')
        return result['access_token']
    else:
        logging.error('Unable to obtain access token')
        logging.error(f"Error was: {result['error']}")
        logging.error(f"Error description was: {result['error_description']}")
        logging.error(f"Error correlation_id was: {result['correlation_id']}")
        raise Exception('Failed to obtain access token')

def main():
    # Setup logging
    try:
        logging.basicConfig(
            level=logging.ERROR,
            format='%asctime)s - %(name)s - %(levelname)s - %(message)s',
            handlers=[logging.StreamHandler(sys.stdout)]
        )
    except:
        logging.error('Failed to setup logging: ', exc_info=True)

    try:
        # Obtain an access token
        token = get_sp_access_token(
            client_id = os.getenv('CLIENT_ID'),
            client_credential = os.getenv('CLIENT_SECRET'),
            tenant_name = os.getenv('TENANT_ID'),
            scopes = "https://cognitiveservices.azure.com/.default"
        )
        print(token)
    except:
        logging.error('Failed to obtain access token: ', exc_info=True)

    try:
        # Setup OpenAI Variables
        openai.api_type = "azure_ad"
        openai.api_base = os.getenv('OPENAI_API_BASE')
        openai.api_key = token
        openai.api_version = "2022-12-01"

        response = openai.Completion.create(
            engine=os.getenv('DEPLOYMENT_NAME'),
            prompt='Once upon a time '
        )

        print(response.choices[0].text)

    except:
        logging.error('Failed to summarize file: ', exc_info=True)


if __name__ == "__main__":
    main()

Let me act like I’m ChatGPT and provide you a summary of what we learned today.

The Azure OpenAI Service has both a management plane and data plane.
The Azure OpenAI Service data plane supports two methods of authentication which include static API keys and Azure AD.
The static API keys provide full permissions on data plane operations. These keys should be rotated in compliance with organizational key rotation policies.
The OpenAI SDK for Python (and I’m going to assume the others) sends an api-key header by default. This behavior can be overridden to send an Authorization header which includes an access token obtained from Azure AD.
It’s recommended you use Azure AD authentication where possible to leverage all the bells and whistles of Azure AD including the usage of managed identities, improved logging, and conditional access for service principal-based access.

Well folks, that concludes this post. I’ll be uploading the code sample above to my GitHub later this week. In the next batch of posts I’ll cover the authorization and logging aspects of the service.

I hope you got some value and good luck in your AI journey!

Identifying Orphaned Managed Identities

Posted on October 19, 2021 by mattfeltonma

Hello again fellow geeks!

Recently I was giving a customer an overview of Azure Managed Identities and came across an interesting find while building a demo environment. If you’re unfamiliar with managed identities, check out my prior series for an overview. Long story short, managed identities provide a solution for non-human identities where you don’t have to worry about storing, securing, and rotating the credentials. For those of you coming from AWS, managed identities are very similar to AWS Roles. They come in two flavors, user-assigned and system-assigned. For the purposes of this post, I’ll be focusing on system-assigned.

Under the hood, a managed identity is essentially a service principal with some orchestration on top of it. Interestingly enough, there are a number of different service principal types. Running the command below will spit back the different types of service principals that exist in your Azure AD tenant.

az ad sp list --query='[].servicePrincipalType' --all | sort | uniq

If you’re interested in seeing the service principals associated with managed identities in your Azure AD tenant, you can run the command below.

az ad sp list --query="[?servicePrincipalType=='ManagedIdentity']" --all

Managed identities include a property called alternativeNames which is an array. In my testing I observed two values within this array. The first value is “isExplicit=True” or “isExplicit=False” which is set to True for user-assigned managed identities and False when it’s a system-assigned managed identity. If you want to see all system-assigned managed identities for example, you can run the command below.

az ad sp list --query="[?servicePrincipalType=='ManagedIdentity' && alternativeNames[?contains(@,'isExplicit=False')]]" --all

The other value in this array is the resource id of the managed identity in the case of a user-assigned managed identity. With a system-assigned managed identity this is the resource id of the Azure resource the system-assigned managed identity is associated with.

System-assigned managed identity

So why does any of this matter? Before we get to that, let’s cover the major selling point of a system-assigned managed identity when compared to a user-assigned managed identity. With a system-assigned managed identity, the managed identity (and its service principal) share the lifecycle of the resource. This means that if you delete the resource, the service principal is cleaned up… well most of the time anyway.

Sometimes this cleanup process doesn’t happen and you’re left with orphaned service principals in your directory. The most annoying part is you can’t delete these service principals (I’ve tried everything including calls direct to the ARM API) and the only way to get them removed is to open a support ticket. Now there isn’t a ton of risk I can think of with having these orphaned service principals left in your tenant since I’m not aware of any means to access the credential associated with it. Without the credential no one can authenticate as it. Assuming the RBAC permissions are cleaned up, it’s not really authorized to do anything within Azure either. However, beyond dirtying up your directory, it’s an identity with a credential that shouldn’t be there anymore.

I wanted an easy way to identify these orphaned system-assigned managed identities so I could submit a support ticket and get it cleaned up before it started cluttering up my demonstration tenant. This afternoon I wrote a really ugly bash script to do exactly that. The script uses some of the az cli commands I’ve listed above to identify all the system-assigned managed identities and then uses az cli to determine if the resource exists. If the resource doesn’t exist, it logs the displayName property of the system-assigned managed identity to a text file. Quick and dirty, but does the job.

Interestingly enough, I had a few peers run the script on their tenants and they all had some of these orphaned system-assigned managed identities, so it seems like this problem isn’t restricted to my tenants. Again, I personally can’t think of a risk of these identities remaining in the directory, but it does point to an issue with the lifecycle management processes Microsoft is using in the backend.

Well folks that’s it! Have a great night!

Python Sample Web App and API for Azure AD B2C

Posted on June 22, 2020 by mattfeltonma

Hello again folks.

I’ve recently had a number of inquiries on Microsoft’s AAD (Azure Active Directory) B2C (Business-To-Consumer) offering. For those infrastructure folks who have had to manage customer identities in the past, you know the pain of managing these identities with legacy solutions such as LDAP (Lighweight Directory Access Protocol) servers or even a collection of Windows AD (Active Directory) forests. Developers have suffered along with us carrying the burden of securely implementing the technologies into their code.

AAD B2C exists to make the process easier by providing a modern IDaaS (identity-as-a-service) offering complete with a modern directory accessible over a Restful API, support for modern authentication and authorization protocols such as SAML, Open ID Connect, and OAuth, advanced features such as step-up authentication, and a ton of other bells and whistles. Along with these features, Microsoft also provides a great library in the form of the Microsoft Authentication Library (MSAL).

It had been just about 4 years since I last experimented with AAD B2C, so I was due for a refresher. Like many people, I learn best from reading and doing. For the doing step I needed an application I could experiment with. My first stop was the samples Microsoft provides. The Python pickings are very slim. There is a basic web application Ray Lou put together which does a great job demonstrating basic authentication. However, I wanted to test additional features like step-up authentication and securing a custom-built API with AAD B2C so I decided to build on top of Ray’s solution.

I began my journey to create the web app and web API I’ll be walking through setting up with this post. Over the past few weeks I spent time diving into the Flask web framework and putting my subpar Python skills to work. After many late nights and long weekends spent reading documentation and troubleshooting with Fiddler, I finished the solution which costs of a web app and web API.

Get the code here.

Screenshot of Python B2C Solution Design

The solution is quite simple . It is intended to simulate a scenario where a financial services institution is providing a customer access the customer’s insurance policy information . The customer accesses a web frontend (python-b2c-web) which makes calls to a API (python-b2c-api) which then retrieves policy information from an accounts database (in this case a simple JSON file). The customer can use the self-service provisioning capability of Azure B2C to create an account with the insurance company, view their policy, and manage the beneficiary on the policy.

AAD B2C provides the authentication to the web front end (python-b2c-web) via Open ID Connect. Access to the user’s policy information is handled through the API (python-b2c-api) using OAuth. The python-b2c-web frontend uses OAuth to obtain an access token which is uses for delegated access to python-b2c-api to retrieve the user’s policy information. The claims included in the access token instruct the python-b2c-api which record to pull. If the user wishes to change the beneficiary on the policy, the user is prompted for step-up authentication requiring an MFA authentication.

The solution uses four Azure AD B2C User Flows. It has a profile editing user flow which allows the user to change information stored in the AAD B2C directory about the user such as their name. A password reset flow allows the user to change the password for their local AAD B2C identity. Two sign-up/sign-in flows exist one with no MFA and one with MFA enforced and two sign-up / sign-in flows. The non-MFA enabled flow is the kicked off at login to python-b2c-web while the MFA enabled flow is used when the user attempts to change the beneficiary.

With the basics on the solution explained, let’s jump in to how to set it up. Keep in mind I’ll be referring to public documentation where it makes sense to avoid reinventing the wheel. At this I’m providing instructions as to how to run the code directly on your machine and additionally instructions for running it using Docker. Before we jump into how to get the code up and running, I’m going to walkthrough setting up Azure AD B2C.

Setting up Azure AD B2C

Before you go setting up Azure AD B2C, you’ll need a valid Azure AD Tenant and Azure Subscription. You can setup a free Azure account here. You will need at least contributor within the Azure Subscription you plan on using to contain the Azure AD B2C directory.

Follow the official documentation to setup your Azure B2C directory once you have your Azure Subscription setup and ready to go. Take note of the name of the single-label DNS name you use for your Azure B2C directory. This will be the unique name you set that prefixes .onmicrosoft.com (such as myb2c.onmicrosoft.com).

Creation of the Azure AD B2C directory will create a resource of type B2C Tenant in the resource group in the Azure Subscription you are using.

In addition to the single-label DNS name, you’ll also need the note down tenant ID assigned to the B2C directory for use in later steps. You can obtain the tenant ID by looking at the B2C Tenant resource in the Azure Portal. Make sure you’re in the Azure AD directory the Azure Subscription is associated with.

Screenshot of Azure AD B2C resource in Azure Resource Group

If you select this resource you’ll see some basic information about your B2C directory such as the name and tenant ID.

Screenshot of Overview of an Azure AD Tenant resource

Once that is complete the next step is to register the web front end (python-b2c-web) and API (python-b2c-api). The process of registering the applications establishes identities, credentials, and authorization information the applications use to communicate with Azure B2C and each other. This is a step where things can get a bit confusing because when administering an Azure AD B2C directory you need to switch authentication contexts to be within the directory. You can do this by selecting your username in the top right-hand corner of the Azure Portal and selecting the Switch Directory link.

Screenshot of how to switch between Azure AD and Azure AD B2C directories

This will bring up a list of the directories your identity is authorized to access. In the screenshot below you’ll see my Azure AD B2C directory giwb2c.onmicrosoft.com is listed as an available directory. Selecting the directory will be me in the context of the B2C directory where I can then register applications and administer other aspects of the B2C directory.

Screenshot showing available directories

Once you’ve switched to the Azure AD B2C directory context you can search for Azure B2C in the Azure search bar and you’ll be able to fully administer the B2C directory. Select the App Registrations link to begin registering the python-b2c-web application.

Screenshot of Azure AD B2C administration options

In the next screen you’ll be see the applications currently registered with the B2C directory. Click the New registration button to begin a new registration.

In the Register an application screen you need to provide information about the application you are registering. You can name the application whatever you’d like as this is used as the display name when viewing registered applications. Leave the Who can use this application or access this API set the Accounts in any identity provider or organizational directory (for authenticating users with user flows). Populate the Redirect URI with URI Azure B2C should redirect the user’s browser to after the user has authenticate. This needs to be an endpoint capable of processing the response from Azure AD B2C after the user has authenticated. For this demonstration application you can populate the URI with http://localhost:5000/getAToken. Within the application this URI will process the authorization code returned from B2C and use it to obtain the ID token of the user. Note that if you want to run this application in App Services or something similar you’ll need to adjust this value to whatever DNS name your application is using within that service.

Leave the Grant admin consent to openid and offline_access permissions option checked since the application requires permission to obtain an id token for user authentication to the application. Once complete hit the Register button. This process creates an identity for the application in the B2C directory and authorizes it to obtain ID tokens and access tokens from B2C.

Screenshot showing how to register the python-b2c-web application

Now that the python-b2c-web application is registered, you need to obtain some information about the application. Go back to the main menu for the B2C Directory, back into the App Registrations and select the newly registered application. On this page you’ll have the ability to administer a number of aspects of the application such as creating credentials for the application to support confidential client flows such as the authorization code flow which this application uses.

Before you do any configuration, take note of the Application (client) ID. You’ll ned this for later steps.

Screenshot of registered application configuration options

The client ID is used to identify the application to the Azure B2C directory, but you still need a credential to authenticate it. For that you’ll go to Certificates & secrets link. Click on the New client secret button to generate a new credential and save this for later.

You will need to register one additional redirect URI. This redirect URI is used when the user authenticates with MFA during the step-up process. Go back to the Overview and click on the Redirect URIs menu item on the top section as seen below.

Screenshot of overview menu and Redirect URIs link

Once the new page loads, add a redirect URI which is found under the web section. The URI you will need to add is http://localhost:5000/getATokenMFA. Save your changes by hitting the Save button. Again, note you will need to adjust this URI if you deploy this into a service such as App Services.

At this point the python-b2c-web (or web frontend) is registered, but you need to now register python-b2c-api (the API). Repeat the steps above to register the python-b2c-api. You’ll select the same except you do not need to provide a redirect URI since the API won’t be directly authenticating the user.

Once the python-b2c-api is registered, go into the application configuration via the App Registrations menu and record the Application (client) ID as you’ll use this to configuration the application later on. After you’ve recorded that information select the Expose an API link. Here you will register the two OAuth scopes I’ve configured in the application. These scopes will be included in the access token obtained by python-b2c-web when it makes calls to python-b2c-api to get policy information for the user.

Select the Add a scope button and you’ll be prompted to set an Application ID URI which you need to set to api. Once you’ve set it, hit the Save and continue button.

Screenshot of setting the Application ID URI for the python-b2c-api

The screen will refresh you’ll be able to add your first scope. I have defined two scopes within the pyton-b2c-api. One is called Accounts.Read which grants access to read policy information and one for Accounts.Write which grants access to edit policy information. Create the scope for the Accounts.Read and repeat the process for Accounts.Write.

As a side note, by default B2C grants application registered with it the offline_access and openid permissions for Microsoft Graph. Since python-b2c-api won’t be authenticating the user and will simply be verifying the access token passed by the python-b2c-web, you could remove those permissions if you want. You can do this through the API permissions link which is located on the application configuration settings of the python-b2c-api.

The last step you have in the B2C portion of Azure is to grant the python-b2c-web application permission to request an access token for the Accounts.Read and Accounts.Write scopes used by the python-b2c-api application To do this you need to go back into the application configuration for the python-b2c-web application and go to the API permissions link. Click the Add a permission link. In the Request API permissions window, select My APIs link and select the python-b2c-api application you registered. Select the two permissions (Accounts.Read and Accounts.Write) and click the Add permissions link.

Screenshot of granting permissions to the python-b2c-web application

To finish up with the permissions piece you’ll grant admin consent to permissions. At the API permissions window, click the Grant admin consent for YOUR_TENANT_NAME button.

Screenshot of granting admin consent to the new permissions

At this point we’ve registered the python-b2c-web and python-b2c-api applications with Azure B2C. We now need to enable some user flows. Azure B2C has an insanely powerful policy framework that powers the behavior of B2C behind the scenes that allow you to do pretty much whatever you can think of. With power comes complexity, so expect to engage professional services if you want to go to the custom policy route. Azure AD B2C also comes with predefined user flows that provide for common user journeys and experiences. Exhaust your ability to use before you go the custom policy route.

For this solution you’ll be using predefined user flows. You will need to create four predefined user flows named exactly as outlined below. You can use the instructions located here for creation of the user flows. When creating the sign-in and sign-up flows (both MFA and non-MFA) make sure to configure the user attributes and application claims to include the Display Name, Email Address, Given Name, and Surname attributes at a minimum. The solution will be expecting these claims and be using them throughout the application. You are free to include additional user attributes and claims if you wish.

Screenshot of user flows that must be created

At this point you’ve done everything you need to to configure Azure B2C. As a reminder make sure you’ve collected the Azure AD B2C single-label DNS name, Azure AD B2C Tenant ID, python-b2c-web application (client) ID and client secret, and python-b2c-api application (client) ID.

In the next section we’ll setup the solution where the code will run directly on your machine.

(Option 1) Running the code directly on your machine

With this option you’ll run the Python code directly on your machine. For prerequisites you’ll need to download and install Visual Studio Code and Python 3.x.

Open up an instance of Visual Studio Code and clone the repository https://github.com/mattfeltonma/python-b2c-sample. The directory structure of the solution is pictured below.

Screenshot of solution directory structure

The python-b2c-web folder contains the web front end application and the python-b2c-api contains the API application. The accounts.json file in the python-b2c-api folder acts as the database containing the policy information. If a user does not have a policy, a policy is automatically created for the user by the python-b2c-api application the first time the user tries to look at the policy information. The app_config.py file in the python-b2c-web folder contains all the configuration options used by python-b2c-web application. It populates any key variables with environment variables you will set in a later step. The app.py files in both directories contain the code for each application. Each folder also contains a Dockerfile if you wish to deploy the solution as a set of containers. See the option 2 running as containers section for steps on how to do this.

Once the repo has cloned you’ll want to open two Terminal instances in Visual Studio Code. You can do this with CTRL+SHIFT+` hotkey. In your first terminal navigate python-b2c-web directory and in the second navigate to the python-b2c-api directory.

In each terminal we’ll setup a Python virtual directory to ensure we don’t add a bunch of unneeded libraries into the operating system’s central Python instance.

Run the command in each terminal to create the virtual environments. Depending on your operating system you may use to specify python3 instead of python before the -m venv env. This is because operating systems like Mac OS X come preinstalled with Python2 which will not work for this solution.

python -m venv env

Once the virtual environments will need to activate the virtual environments. On a Windows machine you’ll use the command below. On a Mac this file will be in env/bin/ directory and you’ll need to run the command source env/bin/activate.

env\Scripts\activate

Next, load the required libraries using pip using the command below. Remember to do this for both terminals. If you run into any errors installing the dependencies for python-b2c-web ensure you update the version of pip used in the virtual environment using the command pip install –upgrade pip.

pip install -r requirements.txt

The environments are now ready to go. Next up you need to set some user variables. Within the terminal for the python-b2c-web create variables for the following:

CLIENT_ID – The application (client) id of the python-b2c-web application you recorded.
CLIENT_SECRET – The client secret of the python-b2c-web application you recorded.
B2C_DIR – The single-label DNS name of the B2C directory such as myb2c.
API_ENDPOINT – The URI of the python-b2c-api endpoint which must this to http://localhost:5001 when running the code directly on your machine. If running this solution on another platform such as Azure App Services you’ll need to set this to whatever the URI you’re using for App Services.

Within the terminal for the python-b2c-api create variables for the following:

CLIENT_ID – application (client) id of the python-b2c-api application you recorded earlier
TENANT_ID – tenant ID of the B2C directory you recorded earlier
B2C_DIR – single-label DNS name of the B2C directory such as myb2c

In Windows you can set these variables by using the command below. If using Mac OS X ensure you export the variables after creation after you set them. Remember to set all of these variables. If you miss one the application will fail to run.

set B2C_DIR=myb2c

Now you can start the python-b2c-web web front end application. To do this you’ll use the flask command. In the terminal you setup for the python-b2c-web application, run the following command:

flask run -h localhost -p 5000

Then in the terminal for the python-simple-web-api, run the following command:

flask run -h localhost -p 5001

You’re now ready to test the app! Open up a web browser and go to http://localhost:5000.

Navigate to the testing the application section <INSERT LINK> for instructions on how to test the application.

(Option 2) Running as containers

Included in the repository is the necessary Dockerfiles to build both applications as Docker images to run as containers in your preferred container runtime. I’m working on a Kubernetes deployment and will that in time. For the purposes of this article I’m going to assume you’ve installed Docker on your local machine.

To get started clone the repository https://github.com/mattfeltonma/python-b2c-sample. The directory structure of the solution is pictured below.

Navigate to the python-b2c-web directory and run the following command to build the image.

docker build --tag=python-b2c-web:v1 .

Navigate to the python-b2c-api directory and run the following command to build the image.

docker build --tag=python-b2c-api:v1 .

Since we need the python-b2c-web and python-b2c-api applications to communicate, we’re going to create a custom bridged network. This will provide a network that will allow both containers to communicate, connect to the Internet to contact Azure B2C, and find each other using DNS. Note that you must use a custom bridged network to support the DNS feature as the default bridged network doesn’t support the containers finding each other by name.

docker network create b2c

Now that the images are built and the network is created you are ready to spin up the containers. When spinning up each container you’ll need to pass a series of environment variables to the containers. The environment variables are as follows:

CLIENT_ID – The application (client) id of the python-b2c-web application you recorded.
CLIENT_SECRET – The client secret of the python-b2c-web application you recorded.
B2C_DIR – The single-label DNS name of the B2C directory such as myb2c.
API_ENDPOINT – The URI of the python-b2c-api endpoint. As long as you name the container running the python-b2c-api with the name of python-b2c-api, you do not need to set this variable.

Within the terminal for the python-b2c-api create variables for the following:

CLIENT_ID – application (client) id of the python-b2c-api application you recorded earlier
TENANT_ID – tenant ID of the B2C directory you recorded earlier
B2C_DIR – single-label DNS name of the B2C directory such as myb2c

Start a container instance of the python-b2c-web application using the following command:

docker run --network=b2c \
--name=python-b2c-web \
--publish=5000:5000 \
--env=B2C_DIR=giwb2c \
--env=CLIENT_ID=<CLIENT_ID_OF_python-b2c-web> \
--env=CLIENT_SECRET=<CLIENT_SECRET_OF_python-b2c-api> \
python-b2c-web:v1

Start a container instance of the python-b2c-api application using the following command:

docker run --network=b2c \
--name=python-b2c-api \
--publish=5001:5001 \
--env=B2C_DIR=giwb2c \
--env=CLIENT_ID=<CLIENT_ID_OF_python-b2c-api> \
--env=TENANT_ID=<TENANT_ID_OF_B2C_DIRECTORY> \
python-b2c-api:v1

Once both containers are created proceed to the Testing the Application section of this post.

Testing the Application

Open a web browser and navigate to http://localhost:5000. The login page below will appear.

Clicking the Sign-In button will open up the B2C sign-in page. Here you can sign-in with an existing B2C account or create a new one. You can also initialize a password reset.

After successfully authenticating you’ll be presented with a simple home page. The Test API link will bring you to the public endpoint of the python-b2c-api application validating that the API is reachable and running. The Edit Profile link will redirect you to the B2C Edit Profile experience. Clicking the My Claims link will display the claims in your ID token as seen below.

Clicking the My Account link causes the python-b2c-web application to request an access token from Azure B2C to access the python-b2c-api and pull the policy information for the user.

Clicking on the Change Beneficiary button will kick off the second MFA-enabled sign-in and sign-up user flow prompting the user for MFA. After successful MFA, the user is redirected to a page where they make the change to the record. Clicking the submit button causes the python-b2c-web application to make a call to the python-b2c-api endpoint modifying the user’s beneficiary on their policy.

That’s about it. Hopefully this helps give you a simple base to mess with Azure AD B2C.

You can get the solution here.

Thanks everyone!

Journey Of The Geek

The chronicles of a Bostonian tech geek navigating through life and technology

Tag Archives: identity

Authentication in Azure OpenAI Service

Identifying Orphaned Managed Identities
